Specification
| Model No. | S12AAF102-S01 |
| Operating Temperature | -40℃ to +125℃ |
| Rating | 2A 30VDC Or 5A 125/250VAC (UL, cUL) 6000 cycles Min.
2A 30VDC Or 5(2.5)A 125/250VAC (ENEC) 50000 cycles Min. 2A 30VDC Or 5(2.5)A 125/250VAC (CQC) 50000 cycles Min. |
| Mechanical Life | 500,00 cycles Min. |
| Insulation Resistance | 100MΩ Min. |
| Dielectric Strength | 1000VAC（50 ~ 60HZ）
1500VAC（50 ~ 60HZ） |
| Housing | UL 94V-0 Thermoplastic |
| Contact | Silver |
| Lever Type | Without Lever |
| Operation Force (OP) | 15±10gf |
| Release Force (RP) | 30gf Min. |
| Pre-Travel (PT) | 1.2mm Max. |
| Over- Travel (OT) | 0.9mm Min. |
| Movement-Differential (DT) | 0.2mm Max. |
| Operation Position (OP) | 9.1±1.6 mm |
| Free Position(FP) | 13mm Max. |
Details Description
The S12AAF102-S01 is an SPDT with 3 Terminal and 5E5 long life 40T125 high-temperature straight lever micro switch. With the UL, ENEC & CQC certification, the switch is suitable for the approval of most countries for electronic parts and components. Meanwhile, the rating of the S12 snap action switch is 5A 125VAC and 250VAC, 2A 30VDC. If your application in the range, you can consider this switch. Besides, buyers also can choose any parameters because we also have many models for options even the OEM service. For example, we can produce an automobile actuator with microswitches inside.
