Product applications: Smart homes such as multi-function telephones, large-scale mixing consoles, household gas appliances, washing machines, dishwashers, etc.; new energy vehicle charging guns, car air conditioning controllers, car door locks, car sensors, and other automotive markets.

Download E Catalog

You can find this series of switches as following below, while due to some models are not listed on the website, if you can not find the microswitch you need, please feel free to contact us! We will recommend the model to you and if you need to see more of our product range, welcome to see our product page.

Model	Temperature	Rating	Electrical Cycles (UL)	Electrical Cycles (EN)	Electrical Cycles (CQC)	UL858
E41	40 T 85	0.1A 125/250VAC	6,000 cycles	50,000 cycles	50,000 cycles
E51	40 T 125	0.1A 125/250VAC	6,000 cycles	50,000 cycles	50,000 cycles
E61	40 T 150	0.1A 125/250VAC	6,000 cycles	50,000 cycles	50,000 cycles
E42	40 T 85	16（4）A 125/250VAC		50,000 cycles	50,000 cycles
		16A 125/250VAC	6,000 cycles
		1/2HP 125VAC	6,000 cycles
		3/4HP 250VAC	6,000 cycles
E52	40 T 125	10.1A 125VL (Tungsten)	6,000 cycles
		0.4A 125VDC	6,000 cycles
		0.2A 250VDC	6,000 cycles
E62	40 T 150	16(4)A 125/250VAC		50,000 cycles	50,000 cycles
		10A 125/250VAC	100,000 cycles
		1/2HP 125/250VAC	100,000 cycles
		1A 30VDC	100,000 cycles
E43	40 T 85	22(8)A 125/250VAC		10,000 cycles	10,000 cycles
		22A 125/250VAC	6,000 cycles
		1HP 125VAC; 2HP 250VAC	6,000 cycles
E53	40 T 125	15.1A 125/250VAC	100,000 cycles
		12A, 125VL	6,000 cycles
E63	40 T 150	22(8)A 125/250VAC		10,000 cycles	10,000 cycles
		22A 125/250VAC	6,000 cycles
		1HP 125VAC; 2HP 250VAC	6,000 cycles
		15.1A 125/250VAC	100,000 cycles
E73	200C	15.1A 125/250VAC	100,000 cycles
		22A 125/250VAC	6,000 cycles			6,000 cycles+9,400 cycles
